Single Phase AN Cast Resin Transformer 33000V 240V 2 Wire

Name: Single Phase AN Cast Resin Transformer 33000V 240V 2 Wire
Brand: WINLEY
Price: 500 USD

Single Phase AN Cast Resin Transformer 33000V 240V 2 Wire Manufactures

Brand Name : WINLEY

Model Number : 5KVA

Certification : ISO,CE

Place of Origin : CHINA

MOQ : 1unit

Price : $500~$60000/Unit

Payment Terms : T/T

Supply Ability : 1000units/month

Delivery Time : 10-15days

Packaging Details : Plywood case

Usage : Distribution Euqipment

Phase : Single phase

Frequency : 50/60Hz

Primary voltage : 33000V

Secondary voltage : 240V

Insulation class : F

Type : 2 wire

Cooling method : AN

Contact Now

Single Phase AN Cast Resin Transformer 33000V 240V 2 Wire

Features

1.It can go deep into load centers, such as high-rise buildings, airports, wharfs, power plants, residential communities or complete sets of substations.

2.The temperature sensing element and the sensing system embedded in the low voltage winding can start and turn off the fan or alarm or trip according to the set value for protection.

Specification

Single Phase AN Cast Resin Transformer 33000V 240V 2 Wire

FAQ

Q: How do transformers been shipped?

A: Transformers always been delivered by ship,train or truck for oversea.

Q: Can your product be customerized?

A: Considering differences in voltage, frequency and other speciality of transformer product in different countries and regions,our product can be customerized according to your requirements.

Q: Do you offer guarantee for the products?

A: Yes. We offer at least two years guarantee for all of our transformers.

Q: Do you accept FAT(Factory Acceptance Test)?

A: Yes. It’s available. We are responsible for each set transformer’s testing.

Q: Do you assign engineer for after-sale service?

A: Yes. For our products,we all show after-sale guide installation adn question inquiry.
